Looking for a reliable Nitinol wire manufacturer with consistent batch quality and full traceability?
ZHP Medical has over 20 years of experience specializing in medical-grade Nitinol shape memory alloys. With a strong focus on advanced thermomechanical processing (TMP), we continuously refine material performance at the microstructural level to overcome key challenges such as superelastic stability, fatigue resistance, and biocompatibility.
Our expertise enables us to deliver highly consistent, batch-to-batch reliable Nitinol materials that meet the demanding requirements of high-end medical device applications. By ensuring stable and precise material properties, we support global medical device manufacturers in advancing minimally invasive technologies.
ZHP Medical’s core strength lies in combining physical metallurgy expertise with real-world medical device requirements, optimizing Nitinol material performance through tightly controlled, end-to-end processing.
Due to the high work-hardening rate of Nitinol, we apply a carefully designed multi-pass cold reduction process to precisely manage equivalent strain at each stage. By controlling dislocation density, we prevent embrittlement caused by dislocation accumulation, ensuring structural stability under complex loading conditions while improving ultimate tensile strength and radial force performance.
Through tightly controlled annealing cycles, we promote uniform grain nucleation and growth, effectively eliminating residual stress from prior processing. This restores ductility and optimizes grain boundary distribution, significantly enhancing both low-cycle and high-cycle fatigue resistance—critical for devices subjected to repeated large-strain deformation in minimally invasive applications.
We strictly follow the industry-standard 0.085" (2.16 mm) redraw billet specification, ensuring stable upstream input for downstream processing. Through precise strain field control, we maintain microstructural continuity from macro-scale bars to fine Nitinol wires, providing a reliable metallurgical foundation and ensuring consistent mechanical properties across batches.
To meet the specific design requirements and processing conditions of downstream medical devices, ZHP Medical offers Nitinol materials in two distinct thermodynamic states. These materials are engineered for direct integration into production, eliminating the need for additional pre-conditioning and improving overall manufacturing efficiency.
Delivery State | Core Physical Characteristics | Technical Advantages | Typical Applications |
|---|---|---|---|
As-drawn (Cold Worked) | High stored energy, high dislocation density, and high Ultimate Tensile Strength (UTS). | Strong Shape Memory Effect (SME) and high shape-setting efficiency; achieves high Loading Plateau Stress and radial resistive force after heat treatment. | Braided stents, scoring balloons, and complex functional components requiring high radial strength. |
Straight Annealed | Fully recovered / recrystallized microstructure, excellent flexibility, and high linear precision. | Superior kink resistance and push ability; excellent compatibility with subsequent machining. | Interventional guidewires, mandrels, and linear support components requiring high elongation and ductility. |
* Standard diameters available: 0.025 mm – 2.0 mm. Custom diameters and tolerances available upon request. Contact us for full Nitinol wire specifications and datasheets.
ZHP Medical provides comprehensive Nitinol processing capabilities, covering both geometric customization and advanced surface treatments to meet diverse medical device performance requirements.
Beyond standard round wire, we offer a wide range of custom Nitinol profiles, including square, flat, triangular, and other application-specific geometries. By precisely controlling the area moment of inertia, we tailor the mechanical response to match device-specific needs—such as enhanced cutting performance in scoring balloons or improved structural integrity in braided stents.
Through controlled electrochemical dissolution, electropolishing removes surface micro-defects and forms a dense, uniform titanium dioxide (TiO₂) passivation layer. This process significantly improves biocompatibility, reduces nickel ion release, and enhances corrosion resistance, making it ideal for long-term implantable devices. Our electropolished Nitinol wire offers one of the highest biocompatibility standards available for implantable medical applications.
A controlled acid treatment removes surface oxide scale, optimizing surface energy and improving adhesion performance for downstream assembly processes.
Forms a stable and uniform oxide layer on the material surface, providing a balance between surface protection and processability, suitable for a wide range of general interventional applications.
The Austenite Finish Temperature (Af) is a critical parameter that defines the functional behavior of Nitinol materials. Through advanced thermal processing and tight process control, ZHP Medical ensures precise Af tuning to meet the performance requirements of different medical applications.
Designed to ensure the material is fully in the austenitic phase at body temperature (37°C), this grade delivers stable and reliable superelasticity and strain recovery. It is widely used in interventional devices such as stents and guidewires, where consistent mechanical response is essential.
Engineered for temperature-triggered shape recovery, this grade enables precise and repeatable shape memory behavior. It is ideal for thermally activated components in orthopedic devices and other active medical systems.
Note: ZHP Medical Af temperature tolerance: ±2°C (standard) / ±1°C (precision grade), verified by DSC (Differential Scanning Calorimetry) testing. Full material certification and lot traceability documents available upon request.
ZHP Medical’s high-performance Nitinol materials are widely used across a broad range of medical device applications.
Applications such as occluders, braided stents, and stent graft frameworks, where excellent superelasticity and fatigue resistance are critical for long-term performance.
Including scoring balloon wires, embolic coils, and vena cava filters, requiring precise mechanical response and reliability under cyclic loading.
Such as endodontic (root canal) files, mandrels, flexible forceps, and orthopedic sutures, leveraging Nitinol’s unique combination of flexibility, shape recovery, and biocompatibility.
ZHP Medical operates under strict medical-grade material standards, supported by a comprehensive end-to-end quality management system—from raw material control to final product delivery.
We provide one-stop engineering support, including application analysis, rapid prototyping, and scalable mass production. Our goal is to help customers accelerate product development cycles, reduce total manufacturing cost, and bring innovative medical devices to market more efficiently.
A: We supply Nitinol wire from 0.025 mm to 2.0 mm in diameter, with custom tolerances available for OD, ovality, and surface finish.
A: Our materials comply with ASTM F2063 and ISO 14894 standards, with full lot traceability, CoC documentation, and DSC test reports provided for every batch.
A: Yes. We supply both superelastic grade (Af: −20°C to 22°C) and shape memory actuator grade (Af > 22°C), with tight Af tolerance of ±1°C–±2°C depending on specification.
A: Yes. We support both small R&D quantities and high-volume production orders. Please contact our engineering team for a customized quotation.
A: We offer electropolishing (EP), chemical pickling, and light oxidation. Each treatment is selected based on device application and biocompatibility requirements.
