· Applied Standard:
ASTM F2633-13 Wrought Seamless Nickel-Titanium Shape Memory Alloy Tube for Medical Devices and Surgical Implants
· Surface Finish:
Outer surface: Oxide / Center-less-ground
Inner surface: Etched / Oxide
· Medical Application:
Catheter Needle Stent Dental Products Nitinol Tube Components
· Type
Stent Tube Catheter Tube
· Dimensional tolerances of Guide Tube：
| OD | OD Tolerances | ID Tolerances |
| OD≤0.3mm | ±0.005mm | ±0.010mm |
| 0.3mm＜OD≤1.5mm | ±0.010mm | ±0.010mm |
| 1.5mm＜OD≤2.5mm | ±0.010mm | ±0.020mm |
| 2.5mm＜OD≤3.5mm | ±0.020mm | ±0.020mm |
| 3.5mm＜OD≤10.0mm | ±0.020mm | ±0.020mm |
10.0mm＜OD
| ±0.030mm | ±0.030mm |
· Dimensional tolerances of Stent Tube：
| OD | OD Tolerances | WT Tolerances |
| 0.3mm＜OD≤0.6mm | ±0.010mm | ±0.010mm |
| 0.6mm＜OD≤1.5mm | ±0.013mm | ±0.013mm |
| 1.5mm＜OD≤2.5mm | ±0.015mm | ±0.015mm |
| 2.5mm＜OD≤3.5mm | ±0.015mm | ±0.015mm |
| 3.5mm＜OD≤5.0mm | ±0.020mm | ±0.025mm |
| 5.0mm＜OD≤8.0mm | ±0.020mm | ±0.025mm |
| OD＞8.0mm | ±0.030mm | ±0.030mm |
